Used Speedstar SS-90K Big Hole 6" ID Top-Head
90,000 lb Hoisting Capacity Used 2005/2006 SS-90K Big Hole Top-Head
Rig is mounted on a Crane Carrier Corporation type chassis, with a Cat C-12 375
HP diesel engine in carrier, which runs all rig hydraulics. * Cat C-15 515 HP deck engine,
* 90,000 lb. tophead pullback capacity, * 90,000 lb. main hoisting capacity, * Retracting, "Big-Hole" top head with a 6" ID & 12,000 ft. lbs. torque, * Deck mounted 1000 CFM x 350 PSI Sullair screw compressor, *Cathead, *
Set up for large cuttings cyclone, * Removeable working platform, with upper retracting slip table, * 10,000 lb. auxilliary winch, * Wire-line hoist, two ea. counter-balanced tong hangers
with hydraulic rams and cables for breakout of drill pipe / drill collars, * 25 gpm water injection
pump, and hammer oil lubricator. This
rig can be set up for conventional air/mud drilling, and for flooded reverse or dual-wall reverse drilling. Rig is in shop for hydraulic repairs, and new hydrauluic hoses
have been purchased, and need to be cut, and installed before rig is ready to drill. The
price for this rig "As is - Where is" is negotiable, but under $400,000.00, plus any taxes, licenses,
and shipping fees. Call me for more details, and updated photos. Jon 916-768-4790 newsomco@pacbell.net
Mid
1990's SS-90K Big Hole With Casing Hammer Package This older rig has been sold, but these photos
remain for imformation purposes.
| This earlier SS-90K has a Casing Hammer Attached |
|
| SS-90K Drilling Dual Wall Reverse Large Diameter |
|
| Speedstar SS90K, Showing Casing Hammer, Cyclone, and Large Working Platform |
|
| SS-90K |
|
